				項目 |
				內容 |
				單位 |
				數值 |
				工作行程
				impulse stroke
				  |
				工作臺移動行程[X軸]
				Workbench moving stroke [X-axis] |
				mm |
				600 |
  |
				工作臺往復速度[X軸]
				Workbench reciprocating speed [X-axis] |
				m/min |
				6 |
  |
				磨頭上下移動行程[Z軸]
				Move the grinding head up and down [Z axis] |
				mm |
				400 |
  |
				磨頭快速升降速度[Z軸]
				Quick rise and fall speed of grinding head [Z axis]
				  |
				Mm/min |
				200 |
  |
				砂輪主軸轉數
				Number of spindle revolutions ofgrindingwheel |
				rpm |
				普通1450/高速3000 |
				工作臺
				staging
				  |
				臺面形式   Table form |
				  |
				電磁圓臺面密紋 |
  |
				臺面尺寸   Table size |
				mm |
				Φ750 |
  |
				最大載重   Maximum load |
				KG |
				1000 |
  |
				最大磨削工件尺寸Maximum grinding workpiece size |
				 直徑X高mm |
				800X400 |
  |
				角度調節    Angle adjustment |
				  |
				±3° |
				精度
				precision
				  |
				X軸最小進給刻度  X-axis minimum feed scale |
				mm |
				0.001 |
  |
				Z軸最小進給刻度  Z-axis minimum feed scale |
				mm |
				0.001 |
  |
				主軸定心錐面跳動
				Runout of Main SpindleOf Grindig Wheel |
				rpm |
				≤0.001 |
  |
				工作臺端面跳動 End face runout of worktable |
				mm |
				普通0.005/高精0.002 |
  |
				加工平面度Machining flatness |
				Mm |
				0.02/1000 |
  |
				表面粗糙度  surface roughness |
				Um |
				Ra0.2 |
				電機功率
				power of motor
				  |
				磨頭主軸電機Grinding head spindle moto |
				KW |
				30kw |
  |
				工作臺電機功率  motor power of work Table |
				KW |
				4KW |
  |
				X軸電機  The X axis motor |
				KW |
				伺服 15Nm   |
  |
				Z軸電機  The Z axis motor |
				KW |
				伺服 15Nm |
  |
				總水管電機 Total water pipe motor |
				KW |
				0.45 |
				箱體
				box |
				磨削液箱(水箱) Grinding fluid tank (water tank) |
				L |
				≧100 |
  |
				液壓系統 hydraulic pressure system |
				L |
				120 |
  |
				潤滑系統 lube oil system |
				L |
				4 |
				機器規格
				Machine specification
				  |
				氣壓需求  Pressure demand |
				Mpa |
				0.4-0.6 |
  |
				電源容量  Power supply capacity |
				KVA |
				約35 |
  |
				電源   source |
				  |
				三相四線,380V、50HZ |
  |
				數控系統  numerical control system |
				  |
				西門子 |
  |
				設備尺寸(長×寬×高)
				Equipment size (length × width × height) |
				mm |
				3100×2000×2600 |
  |
				機床凈重  Net weight |
				KG |
				約5200 |
